Supriya Bhaskaran, Tamara Miličić, Tanja Vidaković-Koch, Vikranth Kumar Surasani,  Evangelos Tsotsas, Nicole Vorhauer-Huget

https://doi.org/10.1016/j.ijhydene.2024.06.268

Investigating the counter-current two-phase flow within the anodic porous transport layer (PTL) of polymer electrolyte membrane water electrolyzers (PEMWEs) is a complex yet intriguing challenge. Until now, the gasliquid invasion processes inside PTLs are only to a limited extent accessible under operation conditions, usually using sophisticated and expensive optical approaches, i.e., neutron imaging. We propose a model-supported experimental method with a fully operating microfluidic PEMWE, that allows to examine pore-scale oxygenwater distributions at the anode with high spatial and temporal resolution. The microfluidic cell is made of transparent Poly-Methyl-Methacrylate (PMMA), and the PTL is simplified by a quasi-2D pore network (PN) with a uniform pore-throat structure in the first preliminary study. The proposed setup is a significant advancement over previous studies, where gas was only injected at a constant flow rate from a single point. Test cases with current densities of 0.1, 1, and 2 A/cm² and water flow rates of 1, 3, 5, and 10 ml/min were realized in the novel setup. We found periodically alternating invasion of oxygen (drainage) and water (imbibition), which were analyzed based on image sequences as well as voltage measurements. The experimental data is additionally supported by pore-scale Lattice Boltzmann (LB) and PN simulations. The preliminary results with the simplified PN structure are used to study the dominating transport mechanisms, revealing that drainage and imbibition occur simultaneously and are affected by evaporation and wetting liquid films formed in sharp pore corners. These phenomena are also expected to occur in more complex PTL structures. The preliminary results can, therefore, be regarded as an important basis for PTL studies, which are structurally more complex.
